Name: XC3S200-4FTG256C
Brand: Xilinx Inc.
SKU: XC3S200-4FTG256C
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Xilinx Inc. XC3S200-4FTG256C

Part No.:: XC3S200-4FTG256C

Manufacturer:: Xilinx Inc.

Package:: 256-LBGA

Datasheet:: XC3S200-4FTG256C.pdf

Description:: IC FPGA 173 I/O 256FTBGA

In Stock:: 3731

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC3S200-4FTG256C Specifications

Package/Case:
256-LBGA
Packaging:
Tray
Series:
Spartan®-3
ProductStatus:
Active
NumberofLABs/CLBs:
480
NumberofLogicElements/Cells:
4320
TotalRAMBits:
221184
NumberofI/O:
173
NumberofGates:
200000
Voltage-Supply:
1.14V ~ 1.26V
MountingType:
Surface Mount
OperatingTemperature:
0°C ~ 85°C (TJ)
