Xilinx Inc. XC3S1500-4FGG456C

Part No.:: XC3S1500-4FGG456C

Manufacturer:: Xilinx Inc.

Package:: 456-BBGA

Datasheet:: XC3S1500-4FGG456C.pdf

Description:: IC FPGA 333 I/O 456FBGA

In Stock:: 3503

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC3S1500-4FGG456C Specifications

Package/Case:
456-BBGA
Packaging:
Tray
Series:
Spartan®-3
ProductStatus:
Active
NumberofLABs/CLBs:
3328
NumberofLogicElements/Cells:
29952
TotalRAMBits:
589824
NumberofI/O:
333
NumberofGates:
1500000
Voltage-Supply:
1.14V ~ 1.26V
MountingType:
Surface Mount
OperatingTemperature:
0°C ~ 85°C (TJ)

XC3S1500-4FGG456C this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including XC3S1500-4FGG456C price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for XC3S1500-4FGG456C to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

XC3S1500-4FGG456C information

Views：

XC3S1500-4FGG456C Typical application Circuitry

The XC3S1500-4FGG456C stands out as an integral part of Xilinx's Spartan-3 FPGA series. Tailored for various digital logic designs, its architecture permits extensive customization, meeting diverse application specifications.

XC3S1500-4FGG456C Key Features:

- Configurable Logic Blocks (CLBs): These are the essence of the FPGA, granting the flexibility to design custom logic functions.

- Block RAMs: Serve as internal storage elements.

- Digital Clock Managers: Deliver reliable clock signal management.

- Multifunctional I/O blocks: These ensure seamless interfacing with different peripheral devices and standards.

- Platform Flash ISP Configuration PROMs: This promotes efficient in-system programming and configuration storage.

Potential Application Domains:

Given its flexible nature, the XC3S1500-4FGG456C can be embedded in a myriad of systems: from telecommunications equipment and video processing setups to robotic controllers and advanced digital signal processing. Let's focus on its role within a Digital Audio Processing System.

XC3S1500-4FGG456C in a Digital Audio Processing System:

Power & Grounding:

- VCC: Attach to the designated power supply voltage.
- GND: Affix all ground pins to the common ground of your setup.

Audio Signal Management:

- Convert the incoming analog audio signal into digital using an ADC (Analog to Digital Converter).

- Direct this digital data to the XC3S1500-4FGG456C for processing.

- Use the FPGA to conduct tasks like audio equalization, noise reduction, or reverb addition.

- Retrieve the altered signal and use a DAC (Digital to Analog Converter) to transform it back to analog for audio output.

JTAG Interface for Programming:

- TDI (Test Data In)
- TDO (Test Data Out)
- TCK (Test Clock)
- TMS (Test Mode Select)

Clocking:

An external crystal oscillator can be employed to deliver the clock signals to the XC3S1500-4FGG456C's GCK pins.

Design Aspects to Mull Over:

1. Filtering via Decoupling Capacitors: For reducing voltage spikes and noise, use decoupling capacitors adjacent to the VCC pins. Common choices involve a combination of 0.1 µF and 10 µF capacitors.

2. Thermal Solutions: Active XC3S1500-4FGG456C chips might produce significant heat. Proper heat dissipation, achieved via heat sinks or even active cooling mechanisms, becomes crucial.

3. External Configuration Storage: As the XC3S1500-4FGG456C doesn't retain its configuration post power down, external configuration memory becomes paramount.

4. Voltage Levels and Compatibility: Maintain consistency in voltage levels, especially when you're connecting the FPGA with other peripherals.

To summarize, when utilized adeptly, the XC3S1500-4FGG456C can redefine the boundaries of digital design, but an in-depth understanding and strategic planning are pivotal to its effective deployment.
