Xilinx Inc. XC2V1500-4FGG676C

Part No.:: XC2V1500-4FGG676C

Manufacturer:: Xilinx Inc.

Package:: 676-BGA

Datasheet:: XC2V1500-4FGG676C.pdf

Description:: IC FPGA 392 I/O 676FBGA

In Stock:: 2569

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC2V1500-4FGG676C Specifications

Package/Case:
676-BGA
Packaging:
Tray
Series:
Virtex®-II
ProductStatus:
Obsolete
NumberofLABs/CLBs:
1920
NumberofLogicElements/Cells:
-
TotalRAMBits:
884736
NumberofI/O:
392
NumberofGates:
1500000
Voltage-Supply:
1.425V ~ 1.575V
MountingType:
Surface Mount
OperatingTemperature:
0°C ~ 85°C (TJ)
