Xilinx Inc. XC2C64A-7CPG56I

Part No.:: XC2C64A-7CPG56I

Manufacturer:: Xilinx Inc.

Package:: 56-LFBGA, CSPBGA

Datasheet:: XC2C64A-7CPG56I.pdf

Description:: IC CPLD 64MC 6.7NS 56CSBGA

In Stock:: 2478

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC2C64A-7CPG56I Specifications

Package/Case:
56-LFBGA, CSPBGA
Packaging:
Tray
Series:
CoolRunner II
ProductStatus:
Active
ProgrammableType:
In System Programmable
DelayTimetpd(1)Max:
6.7 ns
VoltageSupply-Internal:
1.7V ~ 1.9V
NumberofLogicElements/Blocks:
4
NumberofMacrocells:
64
NumberofGates:
1500
NumberofI/O:
45
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
