Xilinx Inc. XC2C384-10TQG144I

Part No.:: XC2C384-10TQG144I

Manufacturer:: Xilinx Inc.

Package:: 144-LQFP

Datasheet:: XC2C384-10TQG144I.pdf

Description:: IC CPLD 384MC 9.2NS 144TQFP

In Stock:: 3252

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC2C384-10TQG144I Specifications

Package/Case:
144-LQFP
Packaging:
Tray
Series:
CoolRunner II
ProductStatus:
Active
ProgrammableType:
In System Programmable
DelayTimetpd(1)Max:
9.2 ns
VoltageSupply-Internal:
1.7V ~ 1.9V
NumberofLogicElements/Blocks:
24
NumberofMacrocells:
384
NumberofGates:
9000
NumberofI/O:
118
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
