Xilinx Inc. XC2C256-7PQG208C

Part No.:: XC2C256-7PQG208C

Manufacturer:: Xilinx Inc.

Package:: 208-BFQFP

Datasheet:: XC2C256-7PQG208C.pdf

Description:: IC CPLD 256MC 6.7NS 208QFP

In Stock:: 3538

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC2C256-7PQG208C Specifications

Package/Case:
208-BFQFP
Packaging:
Tray
Series:
CoolRunner II
ProductStatus:
Obsolete
ProgrammableType:
In System Programmable
DelayTimetpd(1)Max:
6.7 ns
VoltageSupply-Internal:
1.7V ~ 1.9V
NumberofLogicElements/Blocks:
16
NumberofMacrocells:
256
NumberofGates:
6000
NumberofI/O:
173
OperatingTemperature:
0°C ~ 70°C (TA)
MountingType:
Surface Mount

XC2C256-7PQG208C this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including XC2C256-7PQG208C price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for XC2C256-7PQG208C to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

XC2C256-7PQG208C information

Views：

XC2C256-7PQG208C Typical application Circuitry

XC2C256-7PQG208C

A member of Xilinx's CoolRunner-II CPLD (Complex Programmable Logic Device) family is the XC2C256-7PQG208C. This specific model is designed to deliver high performance and low power consumption, making it an ideal choice for a wide range of applications where power efficiency and high-speed logic processing are crucial. The main characteristics and interface information of the XC2C256-7PQG208C are summarized as follows:

1. Power Supply Connections: The device requires a power supply connection to VCC and a connection to the ground (GND). The XC2C256-7PQG208C typically operates at a nominal voltage of 3.3V, but it's essential to check the datasheet for the exact voltage levels and power sequencing requirements to ensure proper functionality and to avoid damaging the device.

2. I/O Configuration: The CPLD features a large number of user-configurable I/O pins, which can be programmed to interface with various digital circuits. The user must set the I/O standard and voltage levels according to the interfacing digital logic levels to ensure compatibility and reliable operation.

3. Configuration: The CPLD must be configured with the desired logic design, which is typically done using a JTAG interface. The configuration data is downloaded to the device, usually from a connected computer or an external memory device, depending on the specific application and system design.

4. Clock Inputs: For designs that require synchronous logic, the XC2C256-7PQG208C provides dedicated clock input pins. It is crucial to provide a stable and clean clock signal to ensure the synchronous logic operates reliably and within the specified performance parameters.

5. Cooling and Thermal Management: Given its PQG208 package, which is a 208-pin QFP (Quad Flat Package), there should be considerations for thermal management depending on the application's operational intensity and ambient conditions. Proper heat dissipation techniques, like using a heat sink or ensuring adequate airflow, may be necessary to maintain optimal operating temperatures.

6. Design and Programming Tools: Software tools for CPLD design, simulation, and programming are offered by Xilinx. Using these tools, designers can develop and implement complex logic circuits, simulate their designs to verify functionality, and program the device using the appropriate hardware interface.

7. Application-Specific Interfaces: Depending on the application, the XC2C256-7PQG208C can be interfaced with various peripherals and devices. The specific interfacing requirements would depend on the I/O standards supported by the CPLD and the peripheral devices.

In integrating the XC2C256-7PQG208C into a system, it's crucial to reference the detailed datasheet and product specifications to understand the device's capabilities, limitations, and specific interfacing requirements thoroughly. Adhering to the recommended operating conditions and interfacing guidelines will ensure reliable operation and longevity of the CPLD in your application.
