Name: XC18V04PC44C
Brand: Xilinx Inc.
SKU: XC18V04PC44C
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Xilinx Inc. XC18V04PC44C

Part No.:: XC18V04PC44C

Manufacturer:: Xilinx Inc.

Package:: 44-LCC (J-Lead)

Datasheet:: XC18V04PC44C.pdf

Description:: IC PROM SER C-TEMP 3.3V 44-PLCC

In Stock:: 3140

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

XC18V04PC44C Specifications

Packaging:
Tube
Series:
-
ProductStatus:
Obsolete
ProgrammableType:
In System Programmable
MemorySize:
4Mb
Voltage-Supply:
3V ~ 3.6V
OperatingTemperature:
0°C ~ 70°C
MountingType:
Surface Mount

XC18V04PC44C this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including XC18V04PC44C price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for XC18V04PC44C to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

XC18V04PC44C information

Views：

XC18V04PC44C Typical application Circuitry

XC18V04PC44C

The XC18V04PC44C is another member of Xilinx's XC18V00 series of configuration PROMs, this time with a 4-megabit storage capacity. It's designed to store configuration data for Xilinx FPGAs and enables the FPGA to retrieve its configuration upon each power-up or reset. The 'PC44' in the part number signifies that this device comes in a 44-pin PLCC (Plastic Leaded Chip Carrier) package. Here's how you would typically interface the XC18V04PC44C with an FPGA:

1. Power Connections: Provide a stable 3.3V supply to the VCC pin(s) of the XC18V04PC44C. All the ground (GND) pins must be connected to the system's ground plane to ensure the device operates reliably.

2. Serial Data Interface: Connect the DOUT (Data Output) pin of the XC18V04PC44C to the FPGA's configuration data input pin. This connection is crucial for transferring the configuration data from the PROM to the FPGA.

3. Clock Connection: The CCLK (Configuration Clock) pin on the XC18V04PC44C should be connected to the corresponding CCLK input on the FPGA. The FPGA drives this clock line during configuration, providing the timing for data transfer.

4. Chip Enable (CE): The CE (Chip Enable) pin on the PROM is used to initiate and enable the configuration process. This should be connected to the appropriate control output from the FPGA, which will drive this pin low to start the configuration process.

5. Write Protect (WP): The WP (Write Protect) pin can be connected to VCC to enable the protection feature, preventing unintentional writes to the device. If dynamic control is needed, this pin can be driven by a GPIO pin from the FPGA or another controller.

6. Ready/Busy (READY/BUSY): This status pin can be connected to an optional status input on the FPGA to indicate the PROM's state. If the PROM is busy, this line can inform the FPGA or another controller that the device is not ready for further commands or data.

7. Reset/Output Enable (RESET/OE): The RESET/OE pin can be used for resetting the PROM or controlling the output drivers. Depending on the specific application, this pin might need to be connected to a reset circuit or directly controlled via an FPGA output.

By properly connecting these pins, ensuring that the power supply is clean and stable, and following the recommended configuration procedures provided by Xilinx, you can successfully integrate the XC18V04PC44C into your FPGA-based system, providing reliable storage and retrieval of configuration data.
