STMicroelectronics VNL5160S5TR-E

Part No.:: VNL5160S5TR-E

Manufacturer:: STMicroelectronics

Package:: 8-SOIC

Datasheet:: VNL5160S5TR-E.pdf

Description:: IC PWR SWITCH N-CHANNEL 1:1 8SO

In Stock:: 2690

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

VNL5160S5TR-E Specifications

Package/Case:
8-SOIC
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
OMNIFET III™, VIPower™
ProductStatus:
Active
SwitchType:
General Purpose
NumberofOutputs:
1
Ratio-Input:Output:
1:1
OutputConfiguration:
Low Side
OutputType:
N-Channel
Interface:
On/Off
Voltage-Load:
36V (Max)
Voltage-Supply(Vcc/Vdd):
3.5V ~ 5.5V
Current-Output(Max):
3.5A
RdsOn(Typ):
160mOhm
InputType:
Non-Inverting
Features:
Auto Restart, Status Flag
FaultProtection:
Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
OperatingTemperature:
-40°C ~ 150°C (TJ)
MountingType:
Surface Mount

VNL5160S5TR-E this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including VNL5160S5TR-E price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for VNL5160S5TR-E to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.
