STMicroelectronics VNI4140KTR

Part No.:: VNI4140KTR

Manufacturer:: STMicroelectronics

Package:: PowerSSO-24

Datasheet:: VNI4140KTR.pdf

Description:: IC PWR DRVR N-CHAN 1:1 PWRSSO24

In Stock:: 2755

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

VNI4140KTR Specifications

Package/Case:
PowerSSO-24
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
VIPower™
ProductStatus:
Active
SwitchType:
General Purpose
NumberofOutputs:
4
Ratio-Input:Output:
1:1
OutputConfiguration:
High Side
OutputType:
N-Channel
Interface:
On/Off
Voltage-Load:
10.5V ~ 36V
Voltage-Supply(Vcc/Vdd):
Not Required
Current-Output(Max):
700mA
RdsOn(Typ):
80mOhm (Max)
InputType:
Non-Inverting
Features:
Status Flag
FaultProtection:
Current Limiting (Fixed), Over Temperature
OperatingTemperature:
-40°C ~ 125°C (TJ)
MountingType:
Surface Mount

VNI4140KTR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including VNI4140KTR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for VNI4140KTR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

VNI4140KTR information

Views：

VNI4140KTR Typical application Circuitry

VNI4140KTR

The VNI4140KTR from Microelectronics is a quad high side smart power solid-state relay in a PowerSSO-24 package. It is designed for driving a wide range of loads, especially for resistive, inductive, and capacitive loads. The device integrates advanced protective features and allows simplified system designs. To implement the VNI4140KTR into your circuit, you may follow the steps below:

1. Power Supply: Connect the VDD pin to the power supply, which should fall within the range recommended by the manufacturer (refer to the data sheet). Additionally, a decoupling capacitor between VDD and GND is suggested to filter out high-frequency noise.

2. Ground: Connect all the GND pins to the system ground. Make sure these connections are low impedance to ensure stable operation.

3. Output Pins: The VNI4140KTR consists of four outputs (OUT1 to OUT4) which are designed to connect to the loads. Make that the loads' current and voltage needs are within the device's specs.

4. Input Pins: The VNI4140KTR also has four input pins (IN1 to IN4) corresponding to the four outputs. These pins are used to control the state of the outputs. Ensure that the control signals comply with the input logic level defined by the manufacturer.

5. Enable Pin: The device provides an enabled pin (EN) that allows the control of the output state globally. Toggle this pin between high and low to enable and disable the outputs, respectively.

6. Status Pin: The DRAG/EN pin can provide diagnostic information, such as open-load in off-state, over temperature, and under voltage. This pin can be monitored to safeguard the system operation.

7. Thermal Considerations: The PowerSSO-24 package includes a heat slug on the bottom. Make sure this slug has a good thermal contact with the PCB to help with heat dissipation.

8. Protection Features: VNI4140KTR has integrated protections including over temperature protection, under voltage shutdown, and load current limitation, reducing the need for additional external components for these purposes.

You should refer to the manufacturer's data sheet for the VNI4140KTR for a complete understanding of the device's requirements and guidelines for circuit design. This will ensure the device operates as intended within its specific range and conditions.
