STMicroelectronics VN920SPTR-E

Part No.:: VN920SPTR-E

Manufacturer:: STMicroelectronics

Package:: 10-PowerSO

Datasheet:: VN920SPTR-E.pdf

Description:: IC PWR DRIVER N-CHAN 1:1 PWRSO10

In Stock:: 2473

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

VN920SPTR-E Specifications

Package/Case:
10-PowerSO
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
VIPower™
ProductStatus:
Obsolete
SwitchType:
General Purpose
NumberofOutputs:
1
Ratio-Input:Output:
1:1
OutputConfiguration:
High Side
OutputType:
N-Channel
Interface:
On/Off
Voltage-Load:
5.5V ~ 36V
Voltage-Supply(Vcc/Vdd):
Not Required
Current-Output(Max):
30A
RdsOn(Typ):
15mOhm (Max)
InputType:
Non-Inverting
Features:
Auto Restart
FaultProtection:
Current Limiting (Fixed), Over Temperature, Over Voltage
OperatingTemperature:
-40°C ~ 150°C (TJ)
MountingType:
Surface Mount

VN920SPTR-E this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including VN920SPTR-E price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for VN920SPTR-E to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

VN920SPTR-E information

Views：

VN920SPTR-E Typical application Circuitry

VN920SPTR-E

The VN920SPTR-E is an integrated circuit designed for high-side switching applications, commonly used in automotive environments to control various loads like lamps, motors, and other actuators. This device is part of a series known for their robust performance, integrating protection and diagnostic features to ensure reliability and safety in automotive electronic systems.

1. Power Supply Connection: The VN920SPTR-E requires a connection to the vehicle's battery or a suitable power supply through its supply voltage pin (Vcc). This pin must be properly connected and filtered to provide stable operation and protect against voltage spikes common in automotive environments.

2. Load Connection: The load is connected to the output pin of the high-side driver. The control input signal is what drives the VN920SPTR-E's ability to turn the load on or off. Ensuring a secure and low-resistance connection to the load is crucial for efficient operation and minimizing power losses.

3. Control Input: The control input pin receives the command signal, typically from a microcontroller or an electronic control unit (ECU), determining whether the load is energized or de-energized. This input must be compatible with the logic level of the controlling device to ensure accurate and responsive operation.

4. Diagnostic and Status Feedback: The VN920SPTR-E often includes a diagnostic output or status feedback pin that provides information about the operational state of the driver and the connected load. This function is crucial for keeping an eye on the system's functionality and health since it enables prompt action in the event that problems are found.

5. Protection Features: Integral to the VN920SPTR-E are various protection mechanisms, such as overcurrent protection, thermal shutdown, and possibly load dump protection, which safeguard the device and the load under abnormal conditions. Connections related to these features may be internal to the IC but are essential for understanding its operation and ensuring the system's overall reliability.

By incorporating the VN920SPTR-E into an automotive circuit, engineers can take advantage of its robust design and smart features, ensuring reliable control of various loads while providing real-time diagnostic feedback and protection against a range of potential faults.
