STMicroelectronics VN7003AHTR

Part No.:: VN7003AHTR

Manufacturer:: STMicroelectronics

Package:: OctaPAK 7+1

Datasheet:: VN7003AHTR.pdf

Description:: IC PWR SWITCH N-CHAN 1:1 OCTAPAK

In Stock:: 2317

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

VN7003AHTR Specifications

Package/Case:
OctaPAK 7+1
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q100
ProductStatus:
Active
SwitchType:
General Purpose
NumberofOutputs:
1
Ratio-Input:Output:
1:1
OutputConfiguration:
High Side
OutputType:
N-Channel
Interface:
On/Off
Voltage-Load:
4.5V ~ 28V
Voltage-Supply(Vcc/Vdd):
Not Required
Current-Output(Max):
80A
RdsOn(Typ):
3.5mOhm
InputType:
Non-Inverting
Features:
-
FaultProtection:
Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage, UVLO
OperatingTemperature:
-40°C ~ 150°C (TJ)
MountingType:
Surface Mount
