Texas Instruments UCD3138RJAR

Part No.:: UCD3138RJAR

Manufacturer:: Texas Instruments

Package:: 40-VFQFN Exposed Pad

Datasheet:: UCD3138RJAR.pdf

Description:: IC DGTL PWR CTRLR 40VQFN

In Stock:: 2133

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

UCD3138RJAR Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Active
Applications:
Digital Power Controller
Voltage-Input:
-
Voltage-Supply:
3V ~ 3.6V
Current-Supply:
100 mA
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount
