STMicroelectronics L6599DTR

Part No.:: L6599DTR

Manufacturer:: STMicroelectronics

Package:: 16-SOIC (0.154, 3.90mm Width)

Datasheet:: L6599DTR.pdf

Description:: IC RESONANT CONVRTR CTRLR 16SOIC

In Stock:: 2082

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

L6599DTR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Not For New Designs
Applications:
Resonant Converter Controller
Voltage-Input:
-
Voltage-Supply:
8.85V ~ 16V
Current-Supply:
3.5 mA
OperatingTemperature:
0°C ~ 105°C
MountingType:
Surface Mount
