Texas Instruments TPS65217DRSLR

Part No.:: TPS65217DRSLR

Manufacturer:: Texas Instruments

Package:: 48-VFQFN Exposed Pad

Datasheet:: TPS65217DRSLR.pdf

Description:: IC PMIC BATT PWR SYST 48VQFN

In Stock:: 3664

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TPS65217DRSLR Specifications

Package/Case:
48-VFQFN Exposed Pad
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
Applications:
Battery Management, Display (LED Drivers), Handheld/Mobile Devices, Power Supply
Current-Supply:
-
Voltage-Supply:
2.75V ~ 5.8V
OperatingTemperature:
-40°C ~ 105°C
MountingType:
Surface Mount
