Its features include:
1. Operating Voltage: Supports a minimum input voltage (Vin) of 3 V and a maximum of 5.5 V.
2. Output Current: Typical output current (Iout) is 0.35 A, with a maximum of 0.5 A.
3. Switching Frequency: Ranges from a minimum of 300 kHz to a maximum of 620 kHz.
4. Output Voltage: The maximum output voltage (Vout) is 11 V.
5. Temperature Range: Operates in temperatures ranging from -40°C to 125°C.
The SN6501QDBVRQ1 is housed in a small 5-Pin SOT-23 package and is designed for automotive applications, meeting AEC-Q100 standards. It is functional safety-capable, offering high primary-side current drive (350 mA max for a 5-V supply and 150 mA max for a 3.3-V supply), and ensures low ripple on the rectified output, which permits the use of small output capacitors.
As a monolithic oscillator/power-driver, the SN6501QDBVRQ1 is particularly suited for small form factor, isolated power supplies in isolated interface applications. It drives a low-profile, center-tapped transformer primary from a 3.3-V or 5-V DC power supply. The secondary can be wound to provide any isolated voltage based on transformer turns ratio. It consists of an oscillator followed by a gate drive circuit that provides complementary output signals to drive ground-referenced N-channel power switches, with internal logic ensuring a break-before-make action between the switches.
When designing a circuit using the SN6501QDBVRQ1, some considerations include:
1. Transformer Selection: Choose a suitable transformer based on the desired turns ratio to achieve the required isolated voltage.
2. Power Supply Voltage: Ensure that the power supply voltage is within the chip's operating range (3.3 V or 5 V).
3. Temperature Considerations: Design the circuit to operate within the chip's specified temperature range (-40°C to 125°C).
4. Safety and Compliance: For automotive applications, ensure compliance with relevant standards such as AEC-Q100.
Incorporating these aspects into the design will ensure optimal performance and reliability of the SN6501QDBVRQ1 in your application.
