Vishay Semiconductor Opto Division TOIM5232-TR3

Part No.:: TOIM5232-TR3

Manufacturer:: Vishay Semiconductor Opto Division

Package:: 20-WFQFN Exposed Pad

Datasheet:: TOIM5232-TR3.pdf

Description:: IC SIR ENDEC IRDA 115.2K 20-QFN

In Stock:: 2230

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TOIM5232-TR3 Specifications

Package/Case:
20-WFQFN Exposed Pad
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Obsolete
Type:
Infrared Encoder/Decoder
Applications:
-
Voltage-SupplyAnalog:
2.7V ~ 3.6V
Voltage-SupplyDigital:
2.7V ~ 3.6V
MountingType:
Surface Mount
