Texas Instruments TMS320C6747DZKBT3

Part No.:: TMS320C6747DZKBT3

Manufacturer:: Texas Instruments

Package:

Datasheet:: TMS320C6747DZKBT3.pdf

Description:: IC DSP FIX/FLOAT POINT 256BGA

In Stock:: 3434

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TMS320C6747DZKBT3 Specifications

Package/Case:
Packaging:
Bulk,Tray
Series:
TMS320C674x
ProductStatus:
Active
Type:
Fixed/Floating Point
Interface:
EBI/EMI, Ethernet MAC, Host Interface, I²C, McASP, SPI, UART, USB
ClockRate:
375MHz
Non-VolatileMemory:
External
On-ChipRAM:
448kB
Voltage-I/O:
3.30V
Voltage-Core:
1.20V
OperatingTemperature:
-40°C ~ 125°C (TJ)
MountingType:
Surface Mount
