ADAU1701JSTZ Typical application Circuitry

ADAU1701JSTZ

A completely programmable DSP audio processor, the ADAU1701JSTZ is made for usage in a range of audio applications, including professional audio equipment, home theater systems, and automobile audio systems. This chip features a 28/56-bit DSP core, four ADC inputs, and two DAC outputs, providing flexibility for audio processing and I/O configuration.

Some of the key parameters and features of ADAU1701JSTZ include:

- 28/56-bit DSP core with 50 MIPS performance

- Four 24-bit ADC inputs with 100 dB SNR

- Two 24-bit DAC outputs with 102 dB SNR

- A variety of digital audio interfaces, such as SPDIF, TDM, and I2S

- On-chip memory for storing data and programs - Support for external memory expansion

Let's consider an application scenario where ADAU1701JSTZ is used in a home theater system.

1. Power Supply Connection:

Connect the 3.3 V power supply to pin 28 (DVDD) and ground to pin 27 (DGND).

2. Audio Input Connection:

Connect the audio input signals to pins 6 (IN0), 7 (IN1), 8 (IN2), and 9 (IN3) as required.

3. Audio Output Connection:

Connect pins 14 (OUT0) and 15 (OUT1) to the left and right speakers, respectively.

4. Digital Audio Interface Connection:

Connect the I2S or TDM interface to pins 16 (BCLK), 17 (LRCLK), and 18 (SDATA) as required.

5. Control Interface Connection:

Connect the I2C or SPI control interface to pins 19 (SCL/CSB), 20 (SDA/MOSI), and 21 (MISO) as required.

When designing the circuit, consider the following:

1. Proper Decoupling:

Decoupling capacitors near the power supply pins can be used to reduce noise and give the ADAU1701JSTZ a steady voltage supply.

2. Audio Signal Conditioning:

Use audio amplifiers and filters to preprocess the audio input and output signals to improve the audio quality.

3. Digital Audio Interface Compatibility:

Ensure compatibility between the digital audio interface of ADAU1701JSTZ and the audio source or sink devices.

4. Control Interface Compatibility:

Ensure compatibility between the control interface of ADAU1701JSTZ and the microcontroller or processor used to configure and control the audio processor.
