Texas Instruments TLV5639IDWR

Part No.:: TLV5639IDWR

Manufacturer:: Texas Instruments

Package:: 20-SOIC (0.295, 7.50mm Width)

Datasheet:: TLV5639IDWR.pdf

Description:: IC DAC 12BIT V-OUT 20SOIC

In Stock:: 2899

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TLV5639IDWR Specifications

Package/Case:
20-SOIC (0.295, 7.50mm Width)
Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
NumberofBits:
12
NumberofD/AConverters:
1
SettlingTime:
7µs
OutputType:
Voltage - Buffered
DifferentialOutput:
No
DataInterface:
Parallel
ReferenceType:
External, Internal
Voltage-SupplyAnalog:
2.7V ~ 3.3V, 5V
Voltage-SupplyDigital:
2.7V ~ 3.3V, 5V
INL/DNL(LSB):
±1.2, ±0.3
Architecture:
String DAC
OperatingTemperature:
-40°C ~ 85°C
