Texas Instruments TLV5638ID

Part No.:: TLV5638ID

Manufacturer:: Texas Instruments

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: TLV5638ID.pdf

Description:: IC DAC 12BIT V-OUT 8SOIC

In Stock:: 410

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TLV5638ID Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tube
Series:
-
ProductStatus:
Active
NumberofBits:
12
NumberofD/AConverters:
2
SettlingTime:
7µs
OutputType:
Voltage - Buffered
DifferentialOutput:
No
DataInterface:
SPI
ReferenceType:
External, Internal
Voltage-SupplyAnalog:
2.7V ~ 3.3V, 5V
Voltage-SupplyDigital:
2.7V ~ 3.3V, 5V
INL/DNL(LSB):
±1.7, ±0.4
Architecture:
String DAC
OperatingTemperature:
-40°C ~ 85°C
