Texas Instruments TLV3502AIDCNR

Part No.:: TLV3502AIDCNR

Manufacturer:: Texas Instruments

Package:: SOT-23-8

Datasheet:: TLV3502AIDCNR.pdf

Description:: IC COMPARATOR R-R HI-SPD SOT23-8

In Stock:: 3043

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TLV3502AIDCNR Specifications

Package/Case:
SOT-23-8
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
Type:
General Purpose
NumberofElements:
2
OutputType:
CMOS, Push-Pull, Rail-to-Rail, TTL
Voltage-SupplySingle/Dual(±):
2.7V ~ 5.5V, ±1.35V ~ 2.75V
Voltage-InputOffset(Max):
6.5mV @ 5.5V
Current-InputBias(Max):
10pA @ 5.5V
Current-Output(Typ):
-
Current-Quiescent(Max):
5mA
CMRRPSRR(Typ):
70dB CMRR, 100dB PSRR
PropagationDelay(Max):
10ns
Hysteresis:
6mV
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount

TLV3502AIDCNR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including TLV3502AIDCNR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for TLV3502AIDCNR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

TLV3502AIDCNR information

Views：

TLV3502AIDCNR Typical application Circuitry

TLV3502AIDCNR

The TLV3502AIDCNR is a dual, high-speed comparator known for its extremely rapid response time and low power consumption. This component is particularly suited for applications that demand quick voltage comparisons and precise timing, such as signal processing in communication systems, industrial control, and automotive applications.

Functionality of the TLV3502AIDCNR

The TLV3502AIDCNR specializes in comparing two input voltages on each of its two channels, providing digital outputs based on these comparisons. It's highly valued for its ability to process signals with minimal delay.

Application Scenarios

1. High-Speed Data Acquisition: Perfect for systems that require rapid signal sampling and processing.

2. Pulse Detection in Medical Equipment: Suitable for detecting specific signal patterns in medical diagnostic tools.

3. Automotive Safety Systems: Used in applications like collision detection systems where fast response times are crucial.

Key Specifications

- Dual High-Speed Operation: Enables the simultaneous comparison of two separate signals.

- Low Power Consumption: Essential for battery-powered or energy-efficient systems.

- Fast Propagation Delay: Provides quick response to changes in input signals.

- Rail-to-Rail Inputs: Allows for a wide range of input signal levels.

Circuit Design: Collision Detection System in Automotive Safety

Creating a detailed circuit using the TLV3502AIDCNR for a collision detection system in an automotive application:

Step 1: Power Supply Integration

- Pin 8 (VDD): Connect to a 5V power source, common in automotive electrical systems.

- Pin 4 (GND): Ground to provide a stable baseline for the circuit.

Step 2: Sensor Signal Inputs

- Pin 2 (IN1-) and Pin 3 (IN1+): Attach these to the output of a front-end sensor that detects potential collision objects.

- Pin 5 (IN2-) and Pin 6 (IN2+): Connect to another sensor, perhaps monitoring a different area or parameter.

Step 3: Output Processing

- Pin 1 (OUT1) and Pin 7 (OUT2): Route these outputs to the vehicle's central control unit, which will take necessary actions based on the comparator's signals.

Step 4: Reference Voltage Setting

- Apply precise reference voltages to IN1- and IN2- (Pins 2 and 5) for defining thresholds for signal comparisons.

Step 5: Noise Reduction

- Place bypass capacitors near the power supply pins to minimize electrical noise and enhance signal integrity.

Design Considerations

- Response Speed: Vital for timely detection and reaction in safety-critical automotive systems.

- Signal Accuracy: Crucial to avoid false positives or negatives in collision detection.

- System Reliability: Essential in automotive environments subject to temperature variations and vibrations.

- Integration with Vehicle Electronics: Important for compatibility with other automotive systems.

In conclusion, the TLV3502AIDCNR is highly suitable for automotive safety applications like collision detection systems, where response speed, signal accuracy, system reliability, and integration with vehicle electronics are key. Designing circuits with the TLV3502AIDCNR involves a detailed approach to ensure these aspects are well-addressed, providing effective and reliable performance in critical automotive safety applications.
