Texas Instruments TLV3501AIDR

Part No.:: TLV3501AIDR

Manufacturer:: Texas Instruments

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: TLV3501AIDR.pdf

Description:: IC COMP 4.5NS R-R HS 8-SOIC

In Stock:: 836

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TLV3501AIDR Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
Type:
General Purpose
NumberofElements:
1
OutputType:
CMOS, Push-Pull, Rail-to-Rail, TTL
Voltage-SupplySingle/Dual(±):
2.7V ~ 5.5V, ±1.35V ~ 2.75V
Voltage-InputOffset(Max):
6.5mV @ 5.5V
Current-InputBias(Max):
10pA @ 5.5V
Current-Output(Typ):
-
Current-Quiescent(Max):
5mA
CMRRPSRR(Typ):
70dB CMRR, 100dB PSRR
PropagationDelay(Max):
10ns
Hysteresis:
6mV
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount
