Texas Instruments TLV3201AIDCKT

Part No.:: TLV3201AIDCKT

Manufacturer:: Texas Instruments

Package:: 5-TSSOP, SC-70-5, SOT-353

Datasheet:: TLV3201AIDCKT.pdf

Description:: IC COMPARATOR RRI SGL SC70-5

In Stock:: 3342

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TLV3201AIDCKT Specifications

Package/Case:
5-TSSOP, SC-70-5, SOT-353
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
ProductStatus:
Active
Type:
General Purpose
NumberofElements:
1
OutputType:
Push-Pull
Voltage-SupplySingle/Dual(±):
2.7V ~ 5.5V
Voltage-InputOffset(Max):
1mV @ 5V
Current-InputBias(Max):
0.005µA @ 5V
Current-Output(Typ):
-
Current-Quiescent(Max):
40µA
CMRRPSRR(Typ):
70dB CMRR, 85dB PSRR
PropagationDelay(Max):
50ns
Hysteresis:
1.2mV
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount
