ON Semiconductor TL431ILPRA

Part No.:: TL431ILPRA

Manufacturer:: ON Semiconductor

Package:: TO-226-3, TO-92-3 (TO-226AA) Formed Leads

Datasheet:: TL431ILPRA.pdf

Description:: IC VREF SHUNT ADJ 2.2% TO92-3

In Stock:: 3138

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TL431ILPRA Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
ReferenceType:
Shunt
OutputType:
Adjustable
Voltage-Output(Min/Fixed):
2.495V
Voltage-Output(Max):
36 V
Current-Output:
100 mA
Tolerance:
±2.2%
TemperatureCoefficient:
50ppm/°C Typical
Noise-01Hzto10Hz:
-
Noise-10Hzto10kHz:
-
Voltage-Input:
-
Current-Supply:
-
Current-Cathode:
1 mA
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Through Hole
