ON Semiconductor TL431ACLPREG
- Part No.:
- TL431ACLPREG
- Manufacturer:
- ON Semiconductor
- Package:
- TO-226-3, TO-92-3 Long Body (Formed Leads)
- Datasheet:
-
TL431ACLPREG.pdf
- Description:
- IC VREF SHUNT ADJ 1% TO92-3
- In Stock:
- 2694
- Quantity:
- Add To Cart
- For more detailed including pricing and shipping
- Quick response, quick quotation
- Flash shipment, no worries after sales
- Original channel, guarantee of the authentic products
Please send RFQ , we will respond immediately.
Purchase and inquiry
TL431ACLPREG Specifications
- Packaging:Tape & Reel (TR),Tape & Reel (TR),Tape & Reel (TR),Cut Tape (CT),Bulk
- Series:-
- ProductStatus:Obsolete
- ReferenceType:Shunt
- OutputType:Adjustable
- Voltage-Output(Min/Fixed):2.495V
- Voltage-Output(Max):36 V
- Current-Output:100 mA
- Tolerance:±1%
- TemperatureCoefficient:50ppm/°C Typical
- Noise-01Hzto10Hz:-
- Noise-10Hzto10kHz:-
- Voltage-Input:-
- Current-Supply:-
- Current-Cathode:1 mA
- OperatingTemperature:0°C ~ 70°C (TA)
- MountingType:Through Hole
