Micro Commercial Co SS8550-C-AP

Part No.:: SS8550-C-AP

Manufacturer:: Micro Commercial Co

Package:: TO-226-3, TO-92-3 (TO-226AA) Formed Leads

Datasheet:: SS8550-C-AP.pdf

Description:: TRANS PNP 25V 1.5A TO92

In Stock:: 2256

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

SS8550-C-AP Specifications

Packaging:
Tape & Box (TB)
Series:
-
ProductStatus:
Obsolete
TransistorType:
PNP
Current-Collector(Ic)(Max):
1.5 A
Voltage-CollectorEmitterBreakdown(Max):
25 V
VceSaturation(Max)@IbIc:
800mV @ 80mA, 800mA
Current-CollectorCutoff(Max):
100nA
DCCurrentGain(hFE)(Min)@IcVce:
120 @ 100mA, 1V
Power-Max:
1 W
Frequency-Transition:
190MHz
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Through Hole

SS8550-C-AP this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including SS8550-C-AP price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for SS8550-C-AP to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

SS8550-C-AP information

Views：

SS8550-C-AP Typical application Circuitry

SS8550-C-AP

SS8550-C-AP is a specific electronic component with distinctive functionalities and applications. This component's role in various circuits is integral due to its unique features.

Application Scenarios for SS8550-C-AP

1. Audio Amplification: Commonly used in audio amplifying circuits for enhancing sound signals.

2. Switching Devices: Apt for switching applications in electronic devices, like power supply circuits.

3. Driver Stages in Amplifiers: Employed in the driver stages of complex amplification systems.

Parameter Features of SS8550-C-AP

- Collector-Base Voltage (VCBO): -40V

- Collector-Emitter Voltage (VCEO): -25V

- Emitter-Base Voltage (VEBO): -6V

- Collector Current (IC): -1.5A

- Total Device Dissipation (Pd): 1W

Detailed Circuit Connection for Audio Amplification

We'll discuss how to use the SS8550-C-AP in an audio amplifier circuit.

1. Configuring Transistor Biasing

- Base Resistor Integration: A resistor should be connected between the base of SS8550-C-AP and the audio input. This resistor is crucial for controlling the base current and setting the operational point of the transistor.

2. Emitter Stability

- Incorporating Emitter Resistor: Include a resistor in the emitter circuit to provide thermal stability and determine the amplifier's gain.

3.Load and Signal Development

- Collector Resistor Configuration: Place a resistor in the collector circuit to develop the output signal and regulate the collector current.

4.AC Coupling

-Input/Output Capacitors: Utilize capacitors at the input (Ci) and output (Co) to block DC components, allowing only AC signals to pass.

5.Power Supply Connections

- VCC and Grounding: The collector of SS8550-C-AP should be connected to a positive voltage supply (VCC), and the emitter to ground through the emitter resistor.

Circuit Design Considerations

- Ensuring Bias Stability: Proper transistor biasing is essential for consistent performance.

- Thermal Management: Adequate cooling is necessary, particularly in high-power applications.

- Distortion Control: Selecting appropriate component values is key to minimizing signal distortion.

When integrating SS8550-C-AP into an audio amplifier circuit, several parameters must be carefully taken into account. The configuration and choice of components should be tailored to meet the specific requirements of the audio amplification application, ensuring optimal performance of the transistor.
