SII1161CTU this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including SII1161CTU price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for SII1161CTU to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.
There is no doubt that you may place an order without registering to icwhale.com.
We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.
For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.
It is recommended to acquire for quotations to get the latest prices and inventories about the parts.
Our sales will reply to your request by email within 24 hours.
1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).
2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.
Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)
The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.
Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.
Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.
Views:
1. Power Connection: The VDD pins of the SII1161CTU should be tied to a 3.3V power supply, and the VSS pins must be grounded. The power supply should cater to the current demands of the chip.
2. Digital Input Interface: The digital inputs (D0-D23) of the SII1161CTU must be connected to the source of your digital video signal. Make sure these inputs match the voltage levels defined in the chip's data sheet.
3. Clock Input: The CL KIN pin should be connected to the clock source for the digital video data. Timing characteristics of this clock are crucial for the chip's operation and should match the specifications outlined in the data sheet.
4. Control Pins: The HS, VS, and DE control pins should be linked to your system's horizontal sync, vertical sync, and data enable signals, respectively.
5. I2C Interface: Connect SDA (Serial Data) and SCL (Serial Clock) pins to your system's I2C bus for control data communication. Proper pull-up resistors should be used as per I2C specifications.
6. TMDS Outputs: The TMDS output pins (TX0-TX2, TXC) are used to send the HDMI/DVI data and clock to the display device. These should be correctly linked to the corresponding inputs of the receiver device, typically via an HDMI connector.
7. Hot Plug Detect: The HPD pin can be linked to the Hot Plug Detect signal from the HDMI connector to detect when a display is connected.
Remember to always refer to the SII1161CTU's data sheet for precise pin assignment, electrical characteristics, and further guidelines. It is crucial to comply with all the design recommendations and safety precautions, including Electrostatic Discharge (ESD) precautions provided in the data sheet, to avert any possible damage to the device.
Additionally, real-life implementations might demand the inclusion of additional components such as decoupling capacitors, pull-up or pull-down resistors, and possibly more, based on the peripherals being used. Therefore, when embedding the SII1161CTU into your circuit design, carefully consider the unique demands of your application.
