Recom Power RO-0505S/HP

Part No.:: RO-0505S/HP

Manufacturer:: Recom Power

Package:: 4-SIP Module

Datasheet:: RO-0505S/HP.pdf

Description:: DC DC CONVERTER 5V 1W

In Stock:: 484

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

RO-0505S/HP Specifications

Package/Case:
4-SIP Module
Packaging:
Tube
Series:
ECONOLINE RO (1W)
ProductStatus:
Active
Type:
Isolated Module
NumberofOutputs:
1
Voltage-Input(Min):
4.5V
Voltage-Input(Max):
5.5V
Voltage-Output1:
5V
Voltage-Output2:
-
Voltage-Output3:
-
Voltage-Output4:
-
Current-Output(Max):
200mA
Power(Watts):
1 W
Voltage-Isolation:
2 kV
Applications:
ITE (Commercial), Medical
Features:
SCP
OperatingTemperature:
-40°C ~ 85°C
Efficiency:
80%
MountingType:
Through Hole
Size/Dimension:
0.45 L x 0.24 W x 0.39 H (11.5mm x 6.0mm x 10.0mm)
ControlFeatures:
ApprovalAgency:

RO-0505S/HP this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including RO-0505S/HP price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for RO-0505S/HP to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

RO-0505S/HP information

Views：

RO-0505S/HP Typical application Circuitry

RO-0505S HP

The RO-0505S/HP is a power module chip designed for DC-DC conversion applications. It provides regulated output voltage from an unregulated input voltage source. This chip is commonly used in various electronic devices to efficiently convert voltage levels, ensuring stable power supply in diverse scenarios.

The RO-0505S/HP has several important qualities, some of them are as follows:

- Compact Size: Due to its tiny form factor, the chip is appropriate for applications where space is limited.

- High Efficiency: It minimizes power losses during voltage adjustment by providing a high efficiency conversion.

- Broad Input Voltage Range: The chip's ability to tolerate a variety of input voltages allows it to be used with a variety of power supply configurations.

- Short Circuit Protection: It incorporates protection mechanisms against short circuits, enhancing the reliability of the circuit.

When designing a circuit with the RO-0505S/HP, several considerations need attention to ensure optimal performance and reliability. These include:

1. Input Voltage Range: Ensure that the input voltage stays within the specified range to prevent damage to the chip.

2. Output Voltage: Determine the appropriate output voltage based on what the connected components need.

3. Load Current: Calculate the load current to determine the power requirements and select an appropriate chip variant capable of handling the load.

4. Heat Dissipation: Consider the heat dissipation requirements, especially if the chip operates under high load conditions.

5. Circuit Layout: Design a proper circuit layout to minimize noise and interference, ensuring stable operation of the chip.

Let's delve into a specific application scenario and provide a detailed circuit design using the RO-0505S/HP chip:

Application Scenario: Battery-Powered Portable Device

In this scenario, we'll design a circuit using the RO-0505S/HP to regulate the voltage supplied to a microcontroller in a battery-powered portable device.

Circuit Design:

1. Input Connection (Pin 1 - Vin): Connect Pin 1 of the RO-0505S/HP to the positive terminal of the battery.

2. Output Connection (Pin 3 - Vout): Connect Pin 3 to the input voltage pin of the microcontroller.

3. Ground Connection (Pin 2 - GND): Connect Pin 2 to the ground (negative terminal) of the battery and the ground pin of the microcontroller.

4. Input Capacitor (Cin): To reduce input voltage swings, sandwich a low ESR electrolytic capacitor between Vin (Pin 1) and GND (Pin 2).

5. Output Capacitor (Cout): To filter high-frequency noise and stabilize the output voltage, connect a ceramic capacitor between Vout (Pin3) and GND (Pin 2).

6. Load (Microcontroller): Connect the microcontroller's power input to Vout (Pin 3) and its ground to GND (Pin 2).

Considerations:

- Ensure the input voltage from the battery remains within the acceptable range specified for the RO-0505S/HP.

- Calculate the microcontroller's maximum current consumption to select an appropriate RO-0505S/HP variant capable of supplying sufficient current.

- Locate the input and output capacitors in close proximity to the chip in order to maximize efficiency and reduce parasitic effects.

- Monitor the temperature of the chip during operation to prevent overheating, especially under high load conditions.

- Carefully test the circuit to ensure that it is reliable and functioning, taking into account variables such as transient response and voltage regulation.

By adhering to these considerations and implementing the detailed circuit design, the RO-0505S/HP can effectively regulate the voltage supplied to the microcontroller, ensuring reliable operation of the battery-powered portable device.
