Texas Instruments REF5045IDGKT

Part No.:: REF5045IDGKT

Manufacturer:: Texas Instruments

Package:: 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)

Datasheet:: REF5045IDGKT.pdf

Description:: IC VREF SERIES 0.05% 8VSSOP

In Stock:: 2465

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

REF5045IDGKT Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
ReferenceType:
Series
OutputType:
Fixed
Voltage-Output(Min/Fixed):
4.5V
Voltage-Output(Max):
-
Current-Output:
10 mA
Tolerance:
±0.05%
TemperatureCoefficient:
3ppm/°C
Noise-01Hzto10Hz:
3µVp-p
Noise-10Hzto10kHz:
-
Voltage-Input:
4.7V ~ 18V
Current-Supply:
1.2mA
Current-Cathode:
-
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount

REF5045IDGKT this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including REF5045IDGKT price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for REF5045IDGKT to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

REF5045IDGKT information

Views：

REF5045IDGKT Typical application Circuitry

REF5045IDGKT

The REF5045IDGKT is a high-precision voltage reference chip, designed to provide a stable and accurate reference voltage in various applications. It's particularly useful in scenarios where precise and stable voltage reference is critical, such as in high-precision instrumentation, data acquisition systems, and medical devices. Let's delve into its features and an example of its application in a circuit.

Key Features of REF5045IDGKT:

- Accurate Voltage Output: The REF5045IDGKT offers a 4.5V output, essential for applications requiring a precise reference voltage.

- Low Noise and Drift: This chip is known for its low noise output and minimal drift, making it ideal for sensitive and high-precision applications.

- Temperature Stability: It maintains performance across various temperature ranges, ensuring reliability in different environments.

Application Scenario: Integration in a High-Accuracy Measurement System

The REF5045IDGKT can be used to supply a steady reference voltage for high-precision Analog-to-Digital Converters (ADCs) in high-accuracy measuring systems. Here's a detailed guide for integrating it:

- Power Supply Connection: Connect the V_IN pin (commonly pin 1) of the REF5045IDGKT to a stable power source. This power supply should be within the specified operating range of the chip.

- Reference Voltage Output: The V_OUT pin (typically pin 2) provides the 4.5V reference and should be connected to the reference voltage input of the ADC.

- Grounding: It is crucial to connect the GND pin (usually pin 3) to the system ground to minimize noise and enhance the stability of the reference voltage.

- Noise Reduction with Bypass Capacitor: A bypass capacitor, such as a 0.1 µF ceramic capacitor, should be placed near the REF5045IDGKT between the V_IN and GND pins to reduce noise.

- Adjustment Features (if applicable): Some circuit designs might permit fine-tuning of the output voltage, though the REF5045IDGKT typically provides a fixed output.

Design Considerations:

When designing a circuit with the REF5045IDGKT, consider the following:

- Power Supply Stability: The power supply to the REF5045IDGKT should be stable and clean, as fluctuations can influence the accuracy of the output voltage.

- Thermal Management: Temperature changes can affect the chip's performance, so managing thermal effects is important.

- Load Regulation: The impact of the connected load on the output voltage stability needs to be evaluated and mitigated if necessary.

Incorporating the REF5045IDGKT into a high-accuracy measurement system involves careful consideration of these factors to utilize the chip's precision and stability, enhancing the overall system performance.
