Texas Instruments REF5025IDGKT

Part No.:: REF5025IDGKT

Manufacturer:: Texas Instruments

Package:: 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)

Datasheet:: REF5025IDGKT.pdf

Description:: IC VREF SERIES 0.05% 8VSSOP

In Stock:: 2087

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

REF5025IDGKT Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
ReferenceType:
Series
OutputType:
Fixed
Voltage-Output(Min/Fixed):
2.5V
Voltage-Output(Max):
-
Current-Output:
10 mA
Tolerance:
±0.05%
TemperatureCoefficient:
3ppm/°C
Noise-01Hzto10Hz:
3µVp-p
Noise-10Hzto10kHz:
-
Voltage-Input:
2.7V ~ 18V
Current-Supply:
1.2mA
Current-Cathode:
-
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount

REF5025IDGKT this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including REF5025IDGKT price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for REF5025IDGKT to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

REF5025IDGKT information

Views：

REF5025IDGKT Typical application Circuitry

REF5025IDGKT

The REF5025IDGKT is a precision voltage reference chip, designed for applications where a highly stable and accurate reference voltage is crucial. It is frequently found in high-end data acquisition systems, medical equipment, and precision instrumentation. Here are its key features and a detailed guide on integrating it into a specific application.

Key Features of REF5025IDGKT :

- Accurate Voltage Output: The REF5025IDGKT typically provides a stable 2.5V output, crucial for applications that require a precise reference voltage.

- Low Noise and High Stability: It offers low noise and excellent stability, making it ideal for sensitive and precision-focused applications.

- Robust Temperature Performance: The chip exhibits a broad temperature range of performance, which guarantees dependability in a variety of settings.

Application Scenario: Use in a High-Precision Data Logging System

In a high-precision data logging system, the REF5025IDGKT can be used to provide a stable reference voltage for an ADC (Analog-to-Digital Converter). Here's how to integrate it:

- Power Supply Connection: Connect the power supply to the V_IN pin (often pin 1) of the REF5025IDGKT. Ensure that the supply voltage is within the chip's recommended operating range.

- Output Voltage to ADC: The reference voltage input of the ADC should be connected to the V_OUT pin (often pin 2) of the REF5025IDGKT, which supplies the 2.5V reference.

- Grounding the Chip: Connect the GND pin (typically pin 3) to the system ground. This is critical for minimizing noise and stabilizing the reference voltage.

- Bypass Capacitor for Noise Reduction: Place a bypass capacitor (like a 0.1 µF ceramic capacitor) close to the REF5025IDGKT, between the V_IN and GND pins, to reduce noise.

- Optional Adjustments: If the design permits, some pins might be used for fine-tuning the output voltage, though the REF5025IDGKT generally provides a fixed output.

Design Considerations :

When designing circuits with the REF5025IDGKT , several aspects must be considered:

- Stable Power Supply: The power supply to the REF5025IDGKT must be stable, as fluctuations can affect the output's accuracy.

- Thermal Management: Consider the thermal impact on the chip, as temperature variations can influence its performance.

- Load Regulation: The connected load's impact on the output voltage stability must be assessed and mitigated if necessary.

In summary, incorporating the REF5025IDGKT into a precision data logging system involves careful consideration of power supply stability, noise reduction techniques, and thermal management to fully utilize the chip's precision and stability features.
