Texas Instruments REF3030AIDBZTG4

Part No.:: REF3030AIDBZTG4

Manufacturer:: Texas Instruments

Package:: TO-236-3, SC-59, SOT-23-3

Datasheet:: REF3030AIDBZTG4.pdf

Description:: IC VREF SERIES 0.2% SOT23-3

In Stock:: 3776

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

REF3030AIDBZTG4 Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Discontinued at Mosen
ReferenceType:
Series
OutputType:
Fixed
Voltage-Output(Min/Fixed):
3V
Voltage-Output(Max):
-
Current-Output:
25 mA
Tolerance:
±0.2%
TemperatureCoefficient:
75ppm/°C
Noise-01Hzto10Hz:
33µVp-p
Noise-10Hzto10kHz:
94µVrms
Voltage-Input:
3.05V ~ 5.5V
Current-Supply:
50µA
Current-Cathode:
-
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount

REF3030AIDBZTG4 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including REF3030AIDBZTG4 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for REF3030AIDBZTG4 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

REF3030AIDBZTG4 information

Views：

REF3030AIDBZTG4 Typical application Circuitry

REF3030AIDBZTG4

The REF3030AIDBZTG4 is a precision, low-dropout, fixed-voltage reference IC, recognized for its stability and low noise. It is frequently utilized in applications that call for a steady voltage reference, like precision instrumentation, battery-operated devices, analog-to-digital converters (ADCs), and digital-to-analog converters (DACs).

Applications:

A typical application for the REF3030AIDBZTG4 is in Precision Data Logging Systems, where accurate and stable voltage references are critical for ensuring measurement accuracy.

Circuit Connection for Precision Data Logging Systems:

1. Power Supply Input: The V_IN pin (typically Pin 3) of the REF3030AIDBZTG4 should be connected to a stable power source. This source needs to be within the IC's specified input voltage range.

2. Reference Voltage Output: Connect the V_OUT pin (usually Pin 2) to the reference voltage input of the data logging system, such as an ADC. This pin provides a precise and stable output voltage.

3. Grounding the IC: The GND pin (commonly Pin 1) needs to be connected to the system's ground. This grounding is crucial for the stability of the reference voltage.

4. Decoupling Capacitors: Place a decoupling capacitor between the V_IN and GND pins near the IC. This capacitor helps to filter out noise from the power supply. Also, a capacitor between V_OUT and GND can enhance the stability of the output voltage.

5. Design for Noise Reduction: In precision data logging systems, it is important to minimize noise around the REF3030AIDBZTG4, especially in the power supply and reference input lines.

Design Considerations:

- Voltage Range Compatibility: Ensure that the supply voltage for the REF3030AIDBZTG4 is within the recommended operational range.

- Load Regulation and Stability: Manage the load connected to the output to maintain the accuracy of the reference voltage.

- Thermal Management: Operate the IC within its temperature limits to avoid overheating and ensure consistent performance.

- Environmental Adaptability: Consider environmental factors such as temperature variations and humidity, especially in outdoor or variable environments.

Conclusion:

The REF3030AIDBZTG4 is well-suited for precision data logging systems, offering a stable and accurate reference voltage crucial for the accuracy of data measurement. Attentive circuit design, focusing on factors like supply stability, load conditions, and noise minimization, is key to leveraging the full potential of this voltage reference IC.
