Texas Instruments REF3030AIDBZRG4

Part No.:: REF3030AIDBZRG4

Manufacturer:: Texas Instruments

Package:: TO-236-3, SC-59, SOT-23-3

Datasheet:: REF3030AIDBZRG4.pdf

Description:: IC VREF SERIES 0.2% SOT23-3

In Stock:: 3957

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

REF3030AIDBZRG4 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Discontinued at Mosen
ReferenceType:
Series
OutputType:
Fixed
Voltage-Output(Min/Fixed):
3V
Voltage-Output(Max):
-
Current-Output:
25 mA
Tolerance:
±0.2%
TemperatureCoefficient:
75ppm/°C
Noise-01Hzto10Hz:
33µVp-p
Noise-10Hzto10kHz:
94µVrms
Voltage-Input:
3.05V ~ 5.5V
Current-Supply:
50µA
Current-Cathode:
-
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount

REF3030AIDBZRG4 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including REF3030AIDBZRG4 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for REF3030AIDBZRG4 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

REF3030AIDBZRG4 information

Views：

REF3030AIDBZRG4 Typical application Circuitry

REF3030AIDBZRG4

The REF3030AIDBZRG4 is a precision, low-dropout, fixed-voltage reference IC. It is well-suited for applications requiring a stable voltage reference with low power consumption, such as in battery-powered devices, analog-to-digital converters (ADCs), digital-to-analog converters (DACs), and precision instrumentation.

Applications:

A prominent application for the REF3030AIDBZRG4 is in Battery-Powered Sensor Systems, where maintaining accuracy over varying power conditions is crucial.

Circuit Connection for Battery-Powered Sensor Systems:

1. Power Supply Input: Connect the V_IN pin (usually Pin 3) of the REF3030AIDBZRG4 to a stable power source. The voltage level of this source should be within the IC's specified input range.

2. Reference Voltage Output: The V_OUT pin (typically Pin 2) provides the stable reference voltage. This should be connected to the reference input of the sensor system, such as an ADC, to ensure precise measurements.

3. Ground Connection: The GND pin (commonly Pin 1) needs to be connected to the circuit's ground for stability and accuracy in the reference voltage.

4. Decoupling Capacitors: It's recommended to place a decoupling capacitor between the V_IN and GND pins near the IC to filter out noise and stabilize the input voltage. Additionally, a capacitor between V_OUT and GND can further enhance the stability of the output voltage.

5. Minimizing Noise and Interference: Given the sensitivity of sensor systems, efforts should be made to shield the REF3030AIDBZRG4 and its connections from electromagnetic interference (EMI) and minimize noise in the circuit.

Design Considerations:

- Supply Voltage Suitability: Ensure that the supply voltage to the REF3030AIDBZRG4 is within its operational range.

- Load Regulation and Stability: The load connected to the output should be managed to maintain the accuracy and stability of the reference voltage.

- Thermal Management: Operate the IC within its temperature limits to prevent overheating and ensure reliable operation.

- Environmental Adaptation: In battery-powered sensor systems, consider the impact of environmental factors such as temperature fluctuations and humidity on circuit performance.

Conclusion:

The REF3030AIDBZRG4 is an excellent choice for battery-powered sensor systems, providing a stable and accurate voltage reference that is essential for maintaining the accuracy of sensor measurements. Proper circuit design, considering factors like power stability, load conditions, and environmental adaptability, is crucial for maximizing the efficacy of this voltage reference IC.
