Texas Instruments REF3025AIDBZR

Part No.:: REF3025AIDBZR

Manufacturer:: Texas Instruments

Package:: TO-236-3, SC-59, SOT-23-3

Datasheet:: REF3025AIDBZR.pdf

Description:: IC VREF SERIES 0.2% SOT23-3

In Stock:: 3739

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

REF3025AIDBZR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
ReferenceType:
Series
OutputType:
Fixed
Voltage-Output(Min/Fixed):
2.5V
Voltage-Output(Max):
-
Current-Output:
25 mA
Tolerance:
±0.2%
TemperatureCoefficient:
75ppm/°C
Noise-01Hzto10Hz:
28µVp-p
Noise-10Hzto10kHz:
80µVrms
Voltage-Input:
2.55V ~ 5.5V
Current-Supply:
50µA
Current-Cathode:
-
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount

REF3025AIDBZR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including REF3025AIDBZR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for REF3025AIDBZR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

REF3025AIDBZR information

Views：

REF3025AIDBZR Typical application Circuitry

REF3025AIDBZR

The REF3025AIDBZR is a low-dropout, low-power, fixed-voltage precision voltage reference IC. It is known for its high stability and low noise, making it suitable for high-precision applications like analog-to-digital converters (ADCs), digital-to-analog converters (DACs), and battery-powered devices.

Applications:

One typical application of the REF3025AIDBZR is in Data Acquisition Systems, where a precise and stable reference voltage is essential for accurate measurements.

Circuit Connection for Data Acquisition Systems:

1. Supply Voltage Input: The V_IN pin of the REF3025AIDBZR (usually Pin 3) should be connected to a stable power source. This power source must be within the IC's specified operating voltage range.

2. Reference Voltage Output: Connect the V_OUT pin (commonly Pin 2) to the reference voltage input of the ADC in the data acquisition system. This pin provides a stable and precise output voltage.

3. Grounding the Device: The GND pin (often Pin 1) needs to be connected to the system's ground. Proper grounding is essential for the stability and accuracy of the voltage reference.

4. Decoupling Capacitors: Place a decoupling capacitor between the V_IN and GND pins, close to the IC. This helps in stabilizing the input voltage and filtering out supply noise. Additionally, a capacitor between V_OUT and GND can provide further stability to the output voltage.

5. Minimizing Noise: Ensure that the layout minimizes noise, especially around the V_OUT pin, as it could impact the accuracy of the data acquisition system.

Design Considerations:

- Voltage Range: The input voltage should be within the range specified for the REF3025AIDBZR.

- Load Regulation: The load on the output voltage should be stable to maintain the accuracy of the reference.

- Thermal Management: Operate the IC within its thermal limits to prevent overheating and ensure reliable performance.

- Environmental Factors: Consider the impact of environmental factors such as temperature and humidity, especially in outdoor or variable temperature applications.

Conclusion:

The REF3025AIDBZR is well-suited for data acquisition systems, offering a precise and stable reference voltage crucial for accurate data measurement. Careful consideration of supply voltage, load stability, and noise minimization in the circuit design can optimize the performance of this voltage reference IC in such applications.
