Texas Instruments REF3020AIDBZRG4

Part No.:: REF3020AIDBZRG4

Manufacturer:: Texas Instruments

Package:: TO-236-3, SC-59, SOT-23-3

Datasheet:: REF3020AIDBZRG4.pdf

Description:: IC VREF SERIES 0.2% SOT23-3

In Stock:: 3599

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

REF3020AIDBZRG4 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Discontinued at Mosen
ReferenceType:
Series
OutputType:
Fixed
Voltage-Output(Min/Fixed):
2.048V
Voltage-Output(Max):
-
Current-Output:
25 mA
Tolerance:
±0.2%
TemperatureCoefficient:
75ppm/°C
Noise-01Hzto10Hz:
23µVp-p
Noise-10Hzto10kHz:
65µVrms
Voltage-Input:
2.098V ~ 5.5V
Current-Supply:
50µA
Current-Cathode:
-
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
