Texas Instruments REF102CU/2K5
- Part No.:
- REF102CU/2K5
- Manufacturer:
- Texas Instruments
- Package:
- 8-SOIC (0.154, 3.90mm Width)
- Datasheet:
-
REF102CU/2K5.pdf
- Description:
- IC VREF SERIES 0.025% 8SOIC
- In Stock:
- 2901
- Quantity:
- Add To Cart
- For more detailed including pricing and shipping
- Quick response, quick quotation
- Flash shipment, no worries after sales
- Original channel, guarantee of the authentic products
Please send RFQ , we will respond immediately.
Purchase and inquiry
REF102CU/2K5 Specifications
- Packaging:Tape & Reel (TR)
- Series:-
- ProductStatus:Active
- ReferenceType:Series
- OutputType:Fixed
- Voltage-Output(Min/Fixed):10V
- Voltage-Output(Max):-
- Current-Output:10 mA
- Tolerance:±0.025%
- TemperatureCoefficient:2.5ppm/°C
- Noise-01Hzto10Hz:5µVp-p
- Noise-10Hzto10kHz:-
- Voltage-Input:11.4V ~ 36V
- Current-Supply:1.4mA
- Current-Cathode:-
- OperatingTemperature:-25°C ~ 85°C (TA)
- MountingType:Surface Mount
