Texas Instruments REF02AUG4
- Part No.:
- REF02AUG4
- Manufacturer:
- Texas Instruments
- Package:
- 8-SOIC (0.154, 3.90mm Width)
- Datasheet:
-
REF02AUG4.pdf
- Description:
- IC VREF SERIES 0.3% 8SOIC
- In Stock:
- 3866
- Quantity:
- Add To Cart
- For more detailed including pricing and shipping
- Quick response, quick quotation
- Flash shipment, no worries after sales
- Original channel, guarantee of the authentic products
Please send RFQ , we will respond immediately.
Purchase and inquiry
REF02AUG4 Specifications
- Packaging:Tube
- Series:REF02
- ProductStatus:Discontinued at Mosen
- ReferenceType:Series
- OutputType:Fixed
- Voltage-Output(Min/Fixed):5V
- Voltage-Output(Max):-
- Current-Output:21 mA
- Tolerance:±0.3%
- TemperatureCoefficient:15ppm/°C
- Noise-01Hzto10Hz:4µVp-p
- Noise-10Hzto10kHz:-
- Voltage-Input:8V ~ 40V
- Current-Supply:1.4mA
- Current-Cathode:-
- OperatingTemperature:-40°C ~ 85°C (TA)
- MountingType:Surface Mount
REF02AUG4 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including REF02AUG4 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for REF02AUG4 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.
Purchase in icwhale.com
There is no doubt that you may place an order without registering to icwhale.com.
We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.
Means of Payment in icwhale.com
For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.
RFQ (Request for Quotations) in icwhale.com
It is recommended to acquire for quotations to get the latest prices and inventories about the parts.
Our sales will reply to your request by email within 24 hours.
Warm reminder
1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).
2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.
Shipping & Handling
Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)
The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.
Shipping Method
Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.
Order Tracking for International Orders
Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.
REF02AUG4 information
Views：
REF02AUG4 Typical application Circuitry
The REF02AUG4 is a precision voltage reference IC manufactured by Texas Instruments. It is designed to provide a stable and accurate reference voltage, typically used in applications like analog-to-digital converters (ADCs), digital-to-analog converters (DACs), and precision power supplies.
Application Scenario: Reference Voltage for ADCs
In an application like a data acquisition system, the REF02AUG4 can be used to provide a stable reference voltage to an ADC, ensuring accurate digital representation of analog signals.
Key Features:
1. Fixed 5V Output Voltage: Provides a stable 5V reference, essential for consistent performance in precision circuits.
2. High Precision: Offers accurate voltage output, critical for sensitive electronics.
3. Low Temperature Coefficient: Reduces output voltage variation with temperature changes, enhancing performance consistency.
4. Wide Input Voltage Range: Supports a broad range of input voltages, adding flexibility to various circuit designs.
Circuit Connection: ADC Reference Voltage
1. Power Supply Connection: Attach a DC power source to the V+ pin (typically pin 8) and connect the V- pin (typically pin 4) to the ground.
2. Reference Output Voltage: Utilize the VOUT pin (typically pin 6) as the reference voltage output for the ADC.
3. Stabilization Capacitor: Place a stabilization capacitor (like 0.1 µF) between the V+ pin and ground near the REF02AUG4 to reduce input supply noise.
4. Connecting to ADC: Link the VOUT pin directly to the reference voltage input of the ADC for precise analog-to-digital conversion.
Design Considerations:
- Input Voltage Range Compliance: Ensure the supply voltage is within the specified range for proper REF02AUG4 operation.
- Load Regulation: Consider the effect of any load changes on the output voltage, particularly in dynamically varying load conditions.
- Temperature Stability: Account for temperature fluctuations in the operating environment that might impact the voltage reference accuracy.
- Noise Management: Implement additional noise reduction measures if necessary, especially in high-precision applications where even minimal noise can impact performance.
In summary, the REF02AUG4 is a highly suitable IC for providing a stable and accurate reference voltage to ADCs in data acquisition systems. Its fixed 5V output, high precision, low temperature coefficient, and wide input voltage range make it ideal for such applications. Key design considerations include input voltage range compliance, load regulation, temperature stability, and noise management to ensure accurate and reliable operation.
