Infineon Technologies PVG612SPBF

Part No.:: PVG612SPBF

Manufacturer:: Infineon Technologies

Package:: 6-SMD (0.300, 7.62mm)

Datasheet:: PVG612SPBF.pdf

Description:: SSR RELAY SPST-NO 1A 0-60V

In Stock:: 3333

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PVG612SPBF this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including PVG612SPBF price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for PVG612SPBF to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

Views：

PVG612SPBF Typical application Circuitry

PVG612SPBF

The PVG612SPBF is a photovoltaic relay similar to the PVG612PBF, designed as a solid-state relay (SSR) with a MOSFET output, typically used for switching and controlling high-voltage loads with a low-voltage control signal.

Application Scenarios:

This SSR is used across various sectors including industrial control systems for switching high voltage equipment, isolation in test equipment, and in the medical industry where electrical isolation is necessary for patient safety.

Key Parameter Features:

- Load voltage capability often reaches up to 60V.

- Ability to handle a load current of up to 1.5A.

- Galvanic isolation between input and output.

- Low drive power requirements and low leakage current.

Circuit Connection Example – Automated Lighting System:

Input Activation:

Connect a digital output pin from a microcontroller or logic gate to the anode of the input LED within the PVG612SPBF, through a current-limiting resistor to activate the SSR.

Control Circuit Powering:

The microcontroller or logic gate should provide a control voltage, typically within 3-5V, to the anode of the input LED, with the cathode going to the system ground.

Output Load Connection:

Connect one terminal of the light fixture or bulb to the positive voltage of your DC power source, and the other terminal to the drain of the MOSFET within the PVG612SPBF.

High-voltage Side Powering:

Connect the common power supply positive to the light fixture, and then to the drain terminal of the MOSFET in the PVG612SPBF. The source terminal of the MOSFET should go to the power supply ground.

Design Considerations:

- Isolation and Safety: Maintain the specified creepage and clearance distances to ensure user safety and proper SSR operation.

- Input Signal Integrity: Use a current-limiting resistor calculated based on the input LED's forward voltage and desired forward current, to prevent damage to the LED.

- Output Load Capacity: Verify that the connected light fixture does not demand more current than the maximum rating of the PVG612SPBF.

- Surge Protection: In some cases, especially with inductive loads, additional surge protection may be needed to protect the MOSFET from voltage spikes.

- Thermal Management: If the relay is expected to conduct high current, ensure adequate heat sinking to prevent overheating.

Using the PVG612SPBF in an automated lighting system provides the advantage of electrical isolation between the low voltage control circuit (like a microcontroller) and the high voltage light fixture. This isolation is particularly important in scenarios where user interaction occurs, providing an additional layer of protection.

PVG612SPBF information

PVG612SPBF Specifications

Package/Case:
6-SMD (0.300, 7.62mm)
Packaging:
Bulk,Tube
Series:
PVG, HEXFET®
ProductStatus:
Active
MountingType:
Surface Mount
Circuit:
SPST-NO (1 Form A)
OutputType:
AC, DC
Voltage-Input:
1.2VDC
Voltage-Load:
0 V ~ 60 V
LoadCurrent:
1 A
On-StateResistance(Max):
500 mOhms
TerminationStyle:
Gull Wing
