NXP USA Inc. PN5321A3HN/C106,51

Part No.:: PN5321A3HN/C106,51

Manufacturer:: NXP USA Inc.

Package:: 40-VFQFN Exposed Pad

Datasheet:: PN5321A3HN/C106,51.pdf

Description:: IC RFID RDR/TRAN 13.56MZ 40HVQFN

In Stock:: 2135

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PN5321A3HN/C106,51 Specifications

Packaging:
Tape & Reel (TR)
Series:
MIFARE®
ProductStatus:
Active
Type:
RFID Reader/Transponder
Frequency:
13.56MHz
Standards:
FeliCa, ISO 14443, MIFARE, NFC
Interface:
I²C, SPI, UART
Voltage-Supply:
2.7V ~ 5.5V
OperatingTemperature:
-30°C ~ 85°C
MountingType:
Surface Mount

PN5321A3HN/C106,51 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including PN5321A3HN/C106,51 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for PN5321A3HN/C106,51 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

PN5321A3HN/C106,51 information

Views：

PN5321A3HN/C106,51 Typical application Circuitry

PN5321A3HN C106,51

The PN5321A3HN/C106,51 is a highly integrated transceiver module for Near Field Communication (NFC) at 13.56 MHz. This chip is widely used for contactless communication at short ranges. Here's an outline of its functionality, typical application scenarios, and key features, followed by a detailed application circuit.

Functionality:

The PN5321A3HN/C106,51 is designed for NFC applications requiring a high degree of integration, enabling the user to implement an NFC solution with a minimum number of external components.

Application Scenarios:

One of the most common applications for the PN5321A3HN/C106,51 is in access control systems where it can be used to read NFC tags for authentication.

Key Features:

- Supports various protocols for NFC communication.

- Integrated RF field detector.

- Integrated data mode detector.

- Accommodates MIFARE and ISO/IEC 14443A.

- FeliCa and ISO/IEC 14443B in reader/writer mode are supported.

- Integrated power supply regulation.

Circuit Connection for an Access Control System:

1. Power Supply:

The PN5321A3HN/C106,51 requires a supply voltage typically ranging from 2.7V to 5.5V. Pin 1 (VDD) should be connected to the positive rail of a regulated power source, while pin 22 (GND) should be connected to the ground.

2. Communication Interface:

For a basic setup, you might use an I2C interface. Pins 11 (SDA) and 12 (SCL) connect to the corresponding SDA and SCL pins on a microcontroller, such as an Arduino. Additionally, pin 13 (IRQ) can be connected to an interrupt-capable pin on the microcontroller to handle interrupt-driven communication.

3. Antenna Connections:

Pins 31 (TX1), 32 (TX2), 35 (RX), and 36 (RX) are connected to the antenna. The antenna design is crucial and must follow the guidelines provided in the datasheet to ensure proper communication range and reliability.

4. Boot Mode Selection:

Pins 2 (SEL0) and 3 (SEL1) are used for selecting the boot mode. For a typical I2C interface, these pins are set to logic level '0' by connecting them to the ground.

5. Optional Hardware Settings:

If hardware page 51 is being used, make sure to connect pin 24 (P5[1]) as per the specific hardware page settings defined by the manufacturer.

Design Considerations:

- Pay close attention to the layout of the antenna circuit to ensure the NFC range is maximized.

- Verify that there is a reliable and clean power source.

- Consider electromagnetic interference and PCB layout to minimize its impact on NFC communication.

- Implement proper decoupling capacitors close to the power supply pins to reduce noise.
