Name: PMBT2907AMYL
Brand: Nexperia USA Inc.
SKU: PMBT2907AMYL
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Nexperia USA Inc. PMBT2907AMYL

Part No.:: PMBT2907AMYL

Manufacturer:: Nexperia USA Inc.

Package:: SC-101, SOT-883

Datasheet:: PMBT2907AMYL.pdf

Description:: PMBT2907AM/SOT883/XQFN3

In Stock:: 3350

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PMBT2907AMYL Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
Automotive, AEC-Q101
ProductStatus:
Active
TransistorType:
PNP
Current-Collector(Ic)(Max):
600 mA
Voltage-CollectorEmitterBreakdown(Max):
60 V
VceSaturation(Max)@IbIc:
1.6V @ 50mA, 500mA
Current-CollectorCutoff(Max):
10nA (ICBO)
DCCurrentGain(hFE)(Min)@IcVce:
100 @ 150mA, 10V
Power-Max:
250 mW
Frequency-Transition:
210MHz
OperatingTemperature:
150°C (TJ)
MountingType:
Surface Mount
