Nexperia USA Inc. PMBT2222AYSX

Part No.:: PMBT2222AYSX

Manufacturer:: Nexperia USA Inc.

Package:: 6-TSSOP, SC-88, SOT-363

Datasheet:: PMBT2222AYSX.pdf

Description:: TRANS NPN 40V 0.6A 6TSSOP

In Stock:: 3028

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PMBT2222AYSX Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q101
ProductStatus:
Active
TransistorType:
NPN
Current-Collector(Ic)(Max):
600 mA
Voltage-CollectorEmitterBreakdown(Max):
40 V
VceSaturation(Max)@IbIc:
1V @ 50mA, 500mA
Current-CollectorCutoff(Max):
10nA (ICBO)
DCCurrentGain(hFE)(Min)@IcVce:
75 @ 10mA, 10V
Power-Max:
250 mW
Frequency-Transition:
300MHz
OperatingTemperature:
150°C (TJ)
MountingType:
Surface Mount
