Nexperia USA Inc. PBSS5540Z/ZLX

Part No.:: PBSS5540Z/ZLX

Manufacturer:: Nexperia USA Inc.

Package:: TO-261-4, TO-261AA

Datasheet:: PBSS5540Z/ZLX.pdf

Description:: TRANS PNP 40V 5A SOT223

In Stock:: 2732

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

PBSS5540Z/ZLX Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
TransistorType:
PNP
Current-Collector(Ic)(Max):
5 A
Voltage-CollectorEmitterBreakdown(Max):
40 V
VceSaturation(Max)@IbIc:
160mV @ 200mA, 2A
Current-CollectorCutoff(Max):
100nA (ICBO)
DCCurrentGain(hFE)(Min)@IcVce:
150 @ 2A, 2V
Power-Max:
2 W
Frequency-Transition:
120MHz
OperatingTemperature:
150°C (TJ)
MountingType:
Surface Mount
