Name: NUD3160LT1G
Brand: ON Semiconductor
SKU: NUD3160LT1G
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

ON Semiconductor NUD3160LT1G

Part No.:: NUD3160LT1G

Manufacturer:: ON Semiconductor

Package:: SOT-23-3 (TO-236)

Datasheet:: NUD3160LT1G.pdf

Description:: IC PWR DRVR N-CHAN 1:1 SOT23-3

In Stock:: 3283

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NUD3160LT1G Specifications

Package/Case:
SOT-23-3 (TO-236)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
MicroIntegration™
ProductStatus:
Active
SwitchType:
Relay, Solenoid Driver
NumberofOutputs:
1
Ratio-Input:Output:
1:1
OutputConfiguration:
Low Side
OutputType:
N-Channel
Interface:
On/Off
Voltage-Load:
61V (Max)
Voltage-Supply(Vcc/Vdd):
Not Required
Current-Output(Max):
150mA
RdsOn(Typ):
1.8Ohm (Max)
InputType:
-
Features:
-
FaultProtection:
-
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
