ON Semiconductor NJVNJD35N04T4G

Part No.:: NJVNJD35N04T4G

Manufacturer:: ON Semiconductor

Package:: TO-252-3, DPak (2 Leads + Tab), SC-63

Datasheet:: NJVNJD35N04T4G.pdf

Description:: TRANS NPN DARL 350V 4A DPAK

In Stock:: 2287

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NJVNJD35N04T4G Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
TransistorType:
NPN - Darlington
Current-Collector(Ic)(Max):
4 A
Voltage-CollectorEmitterBreakdown(Max):
350 V
VceSaturation(Max)@IbIc:
1.5V @ 20mA, 2A
Current-CollectorCutoff(Max):
50µA
DCCurrentGain(hFE)(Min)@IcVce:
2000 @ 2A, 2V
Power-Max:
45 W
Frequency-Transition:
90MHz
OperatingTemperature:
-65°C ~ 150°C (TJ)
MountingType:
Surface Mount
