ON Semiconductor NFVA23512NP2T

Part No.:: NFVA23512NP2T

Manufacturer:: ON Semiconductor

Package:: SPMCA-A34

Datasheet:: NFVA23512NP2T.pdf

Description:: IC PWR N-CH 1:1 SPMCA-A34

In Stock:: 119

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NFVA23512NP2T Specifications

Package/Case:
SPMCA-A34
Packaging:
Bulk,Tube
Series:
-
ProductStatus:
Active
SwitchType:
General Purpose
NumberofOutputs:
1
Ratio-Input:Output:
1:1
OutputConfiguration:
-
OutputType:
N-Channel
Interface:
-
Voltage-Load:
-
Voltage-Supply(Vcc/Vdd):
-
Current-Output(Max):
35A
RdsOn(Typ):
-
InputType:
-
Features:
-
FaultProtection:
-
OperatingTemperature:
-
MountingType:
Through Hole
