ON Semiconductor NCV8403ASTT1G

Part No.:: NCV8403ASTT1G

Manufacturer:: ON Semiconductor

Package:: SOT-223 (TO-261)

Datasheet:: NCV8403ASTT1G.pdf

Description:: IC PWR DRIVER N-CHAN 1:1 SOT223

In Stock:: 2792

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

NCV8403ASTT1G Specifications

Package/Case:
SOT-223 (TO-261)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q101
ProductStatus:
Active
SwitchType:
General Purpose
NumberofOutputs:
1
Ratio-Input:Output:
1:1
OutputConfiguration:
Low Side
OutputType:
N-Channel
Interface:
On/Off
Voltage-Load:
42V (Max)
Voltage-Supply(Vcc/Vdd):
Not Required
Current-Output(Max):
14A
RdsOn(Typ):
53mOhm
InputType:
Non-Inverting
Features:
Auto Restart
FaultProtection:
Current Limiting (Fixed), Over Temperature, Over Voltage
OperatingTemperature:
-40°C ~ 150°C (TJ)
MountingType:
Surface Mount
