ON Semiconductor MMBTA92LT1G

Part No.:: MMBTA92LT1G

Manufacturer:: ON Semiconductor

Package:: TO-236-3, SC-59, SOT-23-3

Datasheet:: MMBTA92LT1G.pdf

Description:: TRANS PNP 300V 0.5A SOT23-3

In Stock:: 3014

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MMBTA92LT1G Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
ProductStatus:
Active
TransistorType:
PNP
Current-Collector(Ic)(Max):
500 mA
Voltage-CollectorEmitterBreakdown(Max):
300 V
VceSaturation(Max)@IbIc:
500mV @ 2mA, 20mA
Current-CollectorCutoff(Max):
250nA (ICBO)
DCCurrentGain(hFE)(Min)@IcVce:
25 @ 30mA, 10V
Power-Max:
300 mW
Frequency-Transition:
50MHz
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
