ON Semiconductor MMBT3904LT1G

Part No.:: MMBT3904LT1G

Manufacturer:: ON Semiconductor

Package:: TO-236-3, SC-59, SOT-23-3

Datasheet:: MMBT3904LT1G.pdf

Description:: TRANS NPN 40V 0.2A SOT23-3

In Stock:: 2279

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MMBT3904LT1G Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
ProductStatus:
Active
TransistorType:
NPN
Current-Collector(Ic)(Max):
200 mA
Voltage-CollectorEmitterBreakdown(Max):
40 V
VceSaturation(Max)@IbIc:
300mV @ 5mA, 50mA
Current-CollectorCutoff(Max):
-
DCCurrentGain(hFE)(Min)@IcVce:
100 @ 10mA, 1V
Power-Max:
300 mW
Frequency-Transition:
300MHz
OperatingTemperature:
-55°C ~ 150°C (TJ)
MountingType:
Surface Mount
