Nexperia USA Inc. MMBT2222A,215

Part No.:: MMBT2222A,215

Manufacturer:: Nexperia USA Inc.

Package:: TO-236-3, SC-59, SOT-23-3

Datasheet:: MMBT2222A,215.pdf

Description:: TRANS NPN 40V 0.6A TO236AB

In Stock:: 2603

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MMBT2222A,215 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
Automotive, AEC-Q101
ProductStatus:
Active
TransistorType:
NPN
Current-Collector(Ic)(Max):
600 mA
Voltage-CollectorEmitterBreakdown(Max):
40 V
VceSaturation(Max)@IbIc:
1V @ 50mA, 500mA
Current-CollectorCutoff(Max):
10nA (ICBO)
DCCurrentGain(hFE)(Min)@IcVce:
100 @ 150mA, 10V
Power-Max:
250 mW
Frequency-Transition:
300MHz
OperatingTemperature:
150°C (TJ)
MountingType:
Surface Mount
