Name: MCZ33996EKR2
Brand: NXP USA Inc.
SKU: MCZ33996EKR2
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

NXP USA Inc. MCZ33996EKR2

Part No.:: MCZ33996EKR2

Manufacturer:: NXP USA Inc.

Package:: 32-SOIC-EP

Datasheet:: MCZ33996EKR2.pdf

Description:: IC PWR SWITCH N-CH 1:16 32SOIC

In Stock:: 2806

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MCZ33996EKR2 Specifications

Package/Case:
32-SOIC-EP
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
ProductStatus:
Active
SwitchType:
General Purpose
NumberofOutputs:
16
Ratio-Input:Output:
1:16
OutputConfiguration:
Low Side
OutputType:
N-Channel
Interface:
SPI
Voltage-Load:
5V ~ 27V
Voltage-Supply(Vcc/Vdd):
3.1V ~ 5.5V
Current-Output(Max):
900mA
RdsOn(Typ):
550mOhm
InputType:
-
Features:
-
FaultProtection:
Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
OperatingTemperature:
-40°C ~ 150°C (TJ)
MountingType:
Surface Mount
