Analog Devices Inc. LT1461BIS8-5#TRPBF

Part No.:: LT1461BIS8-5#TRPBF

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: LT1461BIS8-5#TRPBF.pdf

Description:: IC VREF SERIES 0.06% 8SOIC

In Stock:: 2053

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

LT1461BIS8-5#TRPBF Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Active
ReferenceType:
Series
OutputType:
Fixed
Voltage-Output(Min/Fixed):
5V
Voltage-Output(Max):
-
Current-Output:
100 mA
Tolerance:
±0.06%
TemperatureCoefficient:
7ppm/°C
Noise-01Hzto10Hz:
8ppmp-p
Noise-10Hzto10kHz:
9.6ppmrms
Voltage-Input:
5.5V ~ 20V
Current-Supply:
70µA
Current-Cathode:
-
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount

LT1461BIS8-5#TRPBF this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including LT1461BIS8-5#TRPBF price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for LT1461BIS8-5#TRPBF to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

LT1461BIS8-5#TRPBF information

Views：

LT1461BIS8-5#TRPBF Typical application Circuitry

The LT1461BIS8-5#TRPBF is a Micropower, Precision, Low Dropout Series Voltage Reference from Linear Technology. It offers a highly stable voltage source with a very low power usage. The chip's primary job is to generate a constant voltage despite differences in the power supply, temperature, and circuit load.

Key features of the LT1461BIS8-5#TRPBF include:

- Low Dropout: It can function with very low supply voltage above the output, ideal for low voltage systems.

- High Accuracy: With a typical output error of less than 0.05% at room temperature, it provides excellent precision.

- Low Power Consumption: This chip is a micropower device, consuming very low power making it suitable for battery-powered applications.

- Package: The chip is available in an 8-Lead Plastic SOIC package. The LT1461BIS8-5#TRPBF is typically used in situations requiring a highly accurate reference voltage, such as A/D and D/A conversions, precision power supply, battery-powered systems, and process control systems.

Here's an example of how to use the LT1461BIS8-5#TRPBF as a precision reference for an Analog-to-Digital Converter (ADC):

1. Vout and GND Pins: Connect the output reference voltage (Vout pin 5) to the reference input of the ADC. Link the chip's ground pin (pin 4) to the system ground.

2. Vin Pin: Connect the Vin pin (pin 8) to the supply voltage, which should be slightly higher than the desired output reference voltage.

3. Decoupling Capacitors: Place decoupling capacitors between Vin (pin 8) and GND (pin 4) to filter any high frequency noise from the supply.

4. NFB and SHDN Pins: The NFB pin (pin 3) should be directly connected to the Vout pin (pin 5) unless an external trim resistor is used. The shutdown pin (SHDN, pin 7) can be controlled to turn off the device and save power when not needed. If not used, it should be tied to Vin to prevent it from floating.

5. SENSE Pin: The SENSE pin (pin 6) can be connected to the load to compensate for voltage drops across any series resistance. If not used, connect to Vout.

When designing with the LT1461BIS8-5#TRPBF, the following considerations should be kept in mind:

- Power Supply: Ensure that the power supply voltage is always slightly higher than the desired output voltage to maintain proper operation.

- Thermal Management: Although the chip has a low power operation, thermal management should be considered if operating near its maximum rating.

- Decoupling Capacitors: The value of the decoupling capacitors can significantly affect the stability of the output voltage, so they must be chosen carefully.

In conclusion, the LT1461BIS8-5#TRPBF is a robust and precise voltage reference chip, suitable for systems that require a stable reference voltage with low power consumption.
